TLP 5702 GATE DRIVER OPTOCOUPLER SOP-6

TLP 5702 GATE DRIVER OPTOCOUPLER SOP-6

The TLP5702 is a photo coupler in a 6-pin SO6L package that consists of a GaA ℓAs infrared light-emitting diode(LED) optically coupled to an integrated high-gain, high-speed photodetector IC chip. It provides guaranteed performance and specifications at temperatures up to 110C.

The TLP5702 is physically smaller / thinner than the one in an 8-pin DIP package and compliant with international

nsafety standards for reinforced insulation. Thus, it provides a smaller footprint solution for applications requiring safety standard certification. An internal noise shield provides a guaranteed common-mode transient immunity of ±20 kV/μs.

The TLP5702 is ideal for small to medium-class IGBT and power MOSFET gate drive.

Applications

• Induction Cooktop and Home Appliances
• Industrial Inverters
• Air Conditioner Inverters
• MOSFET Gate Drivers
• IGBT Gate Drivers

Features

• Buffer logic type (totem pole output)
• Output peak current: ±2.5 A (max)
• Operating temperature: -40 to 110C
• Supply current: 3.0 mA (max)
• Supply voltage: 15 to 30 V
• Threshold input current: 5 mA (max)
• Propagation delay time: tpHL/tpLH= 200 ns (max)
• Common-mode transient immunity: ±20 kV/μs (min)
• Isolation voltage: 5000 Vrms (min)
• Safety standards
• UL-approved: UL1577, File No.E67349
• cUL-approved: CSA Component Acceptance Service No.5A File No.E67349
• VDE-approved: EN60747-5-5, EN60065, EN60950-1, EN 62368-1
• CQC-approved: GB4943.1, GB8898
