Suntech IC Module with Hybrid Display

Suntech IC Module with Hybrid Display

• Because of the modified unipolar modulation technique, you can use a mobile phone, CCTV camera, computer mouse, and television without any issues.
• You can enter a model or business name on the display using keypad buttons, mobile phone, or computer anytime.
• Can connect to a computer or mobile phone via USB, making it easy to monitor system operation and parameters and quickly check for any faults.
• Uses a modern and fast processor, so it works quickly and has a low chance of component damage if overloaded or short-circuited.
• If an error occurs (like overload or low PV voltage), the system will automatically reset within seconds.
• If the fault is not fixed after three attempts, you can reset it manually using the keypad.

Options: Suntech IC Module with Hybrid Display

• Select carrier frequency of 6, 12, or 18 kHz.
• Choose between sine wave or modified sine wave.
• Adjust PV voltage, PV current, and output voltage calibration through software (without changing components).
• VMPP setting and output voltage setting.
• Soft start (optional) for easy handling of sudden loads.
• Option to set maximum allowed PV current.
• Option to turn off or continue running if AC voltage is low.

Protection: Suntech IC Module with Hybrid Display

• If PV voltage is too high or low, it shows an error indication.
• If PV current is too high, it shows an error indication.
• If load current is too high, it shows an error indication.
• If heat sink temperature is too high, it shows an error indication.
